GB/T584-1999 Marine Cast Steel Flanged Globe Valves manufacturer from China Deyuan China Fitting Co.,Ltd

GB/T584-1999 Marine Cast Steel Flanged Globe Valves

Payment Terms:	T/T,L/C
Place of Origin:	Chongqing, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Packing: wooden case

Production Capacity: 1000

Delivery Date: 7 days

1.Type:GB/T584-1999 Marine Cast Steel Flanged Globe Valves
2.Type:AS type &BS type
3.Diameter:DN20~DN250
4.Pressure:0.6~6.4Mpa

Marine Cast Steel Flanged Globe Valves

China Deyuan Marine Fitting Co.,ltd are leading supplier of different type of marine valve,we can offer marine gate valve,marine globe valve,marine butterfly valve,marine check valve etc with GB standard,JIS standard,DIN standard,API\ANSI,BS standard etc.Pls contact us for more details

Nominal Pressure(MPa)	Nominal Diameter(mm)	Applicable Medium
1.0	65~300	Fresh water, Lubricanting oil, Fuel oil, t≤300℃ steam.
1.6	100~250
2.5	20~150
4.0	65~100	Fresh water, Lubricanting oil, Fuel oil, t≤400℃ steam.
6.4	20~50	Fresh water, Lubricanting oil, Fuel oil, t≤400℃ steam.

Materials of Main Parts

Parts Name		Material
		Name	Marks
Body/Cover		Cast Steel	ZG230-450
Disc		High-quality Carbon Steel	Steel 25
Stem		Stainless Steel	2Cr13
Disc Seal ring		Weld Stainless Steel	H2Cr13
Body Seal ring	PN≤2.5	Weld Stainless Steel	H1Cr18Ni9Ti
	PN≥4.0	Weld Stainless Steel	H2Cr13
